Optics: Transmission holography - parallax free

Magnification:1x

Eye Relief: Unlimited

Length/Width/Height:3.5"x2.4"x2.8" (91.4X 60.9x71mm)

Weight:11.2 oz (317grams)

Waterproof: Submersible to 33 ft depth

Sealing: Fogproof internal optics

Color/Finish: Non reflective flat dark earth with hard coat finish

Adjustment (per click):0.5 MOA (1/2" at 100 yds)

Adjustment Range:+/- 40 MOA travel

Mount:1" Weaver or (MIL-STD-1913) rail. Adjustable for width variation

Return to Zero: Repeatable to within 2 MOA after re-mounting

Night Vision Compatibility:10 brightness setting (generation I-III+)

Heads-Up-Display Window

Optical Surfaces: Anti-glare coating

Window Dimensions:1.20" x 0.85" (30 x 23mm)

Front Window Material:1/8" solid glass

Rear Window Material: Shatter resistant laminate (3/16" thick)

Field of View (100 yds):30 yds (28m) at a 4" eye relief

Electrical

Brightness Adjustment Range:146,000:1 brightest to lowest

Night Vision Brightness Range:1280:1 with NV switch engaged

Power Source:(1) 123 lithium battery

Battery Life: 600 continuous hours at nominal setting 12

Brightness Settings:30 settings with scrolling feature (10 settings for NV use)

Auto Battery Check Indicator: Flashing reticle upon start-up

Auto Shut-down: At 8 hrs- programmable to 4 hrs

• Single transverse 123 battery to reduce sight length
• Shortened base only requires at most 2 3/4 inch of rail space
• Battery cap and latch are eliminated and replaced with a simple O-ring, tethered cap; better sealing is achieved
• Battery compartment is now separated from the base to allow it to hover over the delta ring of the rifle
• Average battery life at brightness level 12 is roughly 500-600 hours
• Side buttons, NV compatible with a single quick detach throw lever
